PVC Winding Wires Supplier
To keep up with the set international standards, we have incorporated the latest machines and cutting-edge technology to sternly examine the material used for production. In order to attain maximum client satisfaction, we check the product quality on several counts at several stages.
Features :
- High conductivity
- Easy to install
- Dimensional accuracy
Technical Specification
| Conductor Diameter (Nominal) | Thickness of insulation (Minimum) | Overall Diameter | Cond.Rest Max at 20°C Ohm/Km | Elongation of wire (Percentage) | |
| (Minimum) | (Maximum) | ||||
| 0.5 | 0.25 | 1 | 1.15 | 89.6 | 25 |
| 0.6 | 0.25 | 1.1 | 1.25 | 62.2 | 26 |
| 0.7 | 0.3 | 1.3 | 1.45 | 45.7 | 28 |
| 0.8 | 0.3 | 1.4 | 1.55 | 35 | 28 |
| 0.9 | 0.3 | 1.5 | 1.65 | 27.6 | 29 |
| 1 | 0.3 | 1.6 | 1.75 | 22.4 | 30 |
| 1.1 | 0.3 | 1.7 | 1.85 | 18.5 | 30 |
| 1.2 | 0.3 | 1.8 | 1.95 | 15.5 | 31 |
| 1.3 | 0.3 | 1.9 | 2.05 | 13.2 | 32 |
| 1.4 | 0.35 | 2.1 | 2.25 | 11.4 | 32 |
| 1.5 | 0.35 | 2.2 | 2.35 | 9.95 | 32 |
| 1.6 | 0.35 | 2.3 | 2.45 | 8.75 | 32 |
| 1.7 | 0.35 | 2.4 | 2.55 | 7.75 | 32 |
| 1.8 | 0.35 | 2.5 | 2.7 | 6.91 | 32 |
| 1.9 | 0.35 | 2.6 | 2.8 | 6.2 | 32 |
| 2 | 0.45 | 2.9 | 3.1 | 5.6 | 33 |
| 2.1 | 0.45 | 3 | 3.2 | 5.08 | 33 |
| 2.2 | 0.45 | 3.1 | 3.3 | 4.63 | 33 |
| 2.3 | 0.45 | 3.2 | 3.4 | 4.23 | 33 |
| 2.4 | 0.5 | 3.4 | 3.6 | 3.89 | 33 |
| 2.5 | 0.5 | 3.5 | 3.7 | 3.58 | 33 |
| 2.6 | 0.5 | 3.6 | 3.8 | 3.31 | 34 |
| 2.7 | 0.5 | 3.7 | 3.9 | 3.07 | 34 |
| 2.8 | 0.55 | 3.9 | 4.1 | 2.86 | 34 |
| 2.9 | 0.55 | 4 | 4.2 | 2.66 | 34 |
| 3 | 0.55 | 4.1 | 4.3 | 2.49 | 34 |
| 3.2 | 0.7 | 4.6 | 4.8 | 2.19 | 35 |
| 3.4 | 0.75 | 4.9 | 5.1 | 1.94 | 35 |
| 3.6 | 0.75 | 5.1 | 5.3 | 1.73 | 36 |
| 3.8 | 0.75 | 5.3 | 5.5 | 1.55 | 36 |
| 4 | 0.9 | 5.8 | 6 | 1.4 | 37 |
